Elecbee WM8960 Audio Board Stereo CODEC Audio Module Play/Record with 8 Omega 5W Speaker for Raspberry Pi

SKU: EB0049898

Favorites

Key Features

u200a
u200aIntegrates high-quality MEMS silicon Mic, supports sound recording
Onboard standard 3.5mm 4-segment earphone jack, allows sound recording via external earphones with Mic
Onboard dual-channel speaker interface, directly drives speakers
Supports common audio sampling rates such as 8/11.025/22.05/44.1/48KHz, etc.
Supports sound effects such as stereo, 3D surrounding, etc.
Comes with development resources and manual (STM32 examples for playing, recording)
u200a
u200aSpecifications:
u200a
u200aCODEC: WM8960
Operating voltage: 3.3V
Control interface: I2C
Audio interface: I2S
Audio format: WAV
DAC signal-noise ratio: 98dB
ADC signal-noise ratio: 94dB
Earphone driver: 40mW (16Ωa3.3V)
Speaker driver: 1W per channel (8Ω BTL)
u200aSpeaker:
u200aImpedance: 8Ω
Power: 5W
Dimension: 100mm x 45mm x 21 mm
u200a
u200a

Specifications

Show Similar Products (2768) >

Attribute

Value

MCU/SoC Model

WM8960 Audio Stereo

CPU Architecture

TIONIMAGE0

Memory

Raspberry Pi OS / Linux
