Elecbee CO2 Carbon Dioxide Detector Module Air Quality Gas Sensor Tester Detector with 2.8Inch TFT Display

SKU: EB0043718

Favorites

Key Features

-Acrylic clear case shell, high transmittance to be looked through

-Built in for ARM 32 bit processor, accurate detection & system fluency

-2.8 "TFT screen, colorization display, wide angle vision up to 180 °

-High sensitivity sensor ensures the high accuracy in data collections

-Semi-closing design performs excellent in heat radiation, long-life use

-Multipurpose in air quality detection in Carbon Dioxide, temperature & humidity

-Real-time detection results will be shown on screen in corresponding colors related to collected datas

-Lightweight, easy to use and be a straightaway in data interpretation

-Power supply in DC 5V universal, usb socket, car charger, power bank, etc

-Suitable for home / office and car or part scope on air quality detection

Specifications

Show Similar Products (2768) >

Attribute

Value

Wireless Capability

Bluetooth + Cellular

USB Support

USB

Show Similar Products (2768) >

Shipping Guide

Shipping	Delivery Period	For in-stock parts, orders are estimated to ship out in 3 days. Elecbee ships orders once a day at about 5pm except Sunday. Once shipped, estimated delivery time depends on the below carriers you chose. DHL Express: 3-7 business days DHLeCommerce: 12-22 business days FedEx International Priority: 3-7 business days EMS: 10-15 business days Registered Air Mail: 15-30 business days
	Shipping Rates	Shipping rates for your order can be found in the shopping cart.
	Shipping Options	Shipping rates for your order can be found in the shopping cart.
	Shipping Tracking	We will notify you by email with tracking number once order is shipped. You can track your order using the “Track My Order” feature.
Returning/Warranty	Returning	Returns are normally accepted when completed within 30 days from date of shipment, please contact customer service for a return authorization. Parts should be unused and in original packaging. Customer has to take charge for the shipping
	Warranty	All Elecbee purchases come with a 30-day money-back return policy, plus 1-year Elecbee warranty against any manufacturing defects.
		This warranty shall not apply to any item where defects have been caused by improper customer assembly failure by customer to follow instructions, product modification, negligent or improper operation
Ordering	How to Buy	Elecbee accepts online orders.
		Add to cart > Check out > Submit order > Complete payment > Delivery
	Payment	PayPal, Credit Card includes Visa, Master, American Express, Bank transfer.

Description

Specifications:

Material: Acrylic Case + Electronic Components

Size: Approx. 8.5x6.5x3.7cm / 3.35x2.56x1.46 "

Processor: For ARM 32 Bit Chips

Sensor Chip: SensorAir S8 0053

Measurement principle: Non-dispersive infrared principle

Measurement accuracy: ± 40ppm

Font color: Multi Colors

Screen: 2.8 "TFT (2 different display)

Resolution Ratio: 320x240

Power Supply: DC 5V

Operation Current: 1-2A

Temperature Measure Range: -20 to 60 ℃

Accuracy: ± 0.1 ℃

Language Version: English

Working Principle:

When infrared light passes through the gas to be measured, these gas molecules absorb infrared light of a specific wavelength, and its absorption relationship obeys the Lambert-Beer absorption law. The concentration of the gas is measured by the change in light intensity. Between the vibrations, the gas molecules have different, specific atomic absorption wavelengths in the infrared band, so the gas concentration can be detected by measuring the absorption of optical energy at specific wavelengths. Inside the gas chamber, the infrared light source emits light in the infrared band . The energy of the light is absorbed by the gas in the gas chamber. The total energy absorbed corresponds to the concentration of all the gases in the gas chamber. Since the radiation detector integrates an infrared filter for a specific wavelength of the measured gas, it only responds to this specific wavelength. The electrical signal obtained by the detector corresponds to the light energy absorbed by the ga s.

1 x Carbon Dioxide Air Quality Detector

1 x USB Cable
