Elecbee Aviation Circular Waterproof Male Plug and Female Socket TE+Z WF55/4pin Straight Connector

SKU: EB-WF55J4TE-WF55K4Z
Favorites
Key Features
Show More
Specifications
Show Similar Products (2768) >
Attribute
Value
Search
Connector Style
WF55
Shell Size
55
Color
Silver
Numberof Positions
4芯
Mounting Type
Panel Mount
Rated Current
50A,150A
Body Finish
Chrome Plated
Contact Material
Brass
Contact Finish
Gold
Insulation Color
Black
Features
Waterproof
Gender
Plug, Receptacle
Orientation
Straight
Fastening Type
Threaded
Contact Type
Male，Female Pin
Contact Temination
Solder
Rated Voltage
500VAC
Body Material
Zinc Alloy
Insulating Materials
PPS
CableOD
7AWG,2/0AWG
Working Temperature
-40℃~+85℃
Ingress Protection
IP65
Show Similar Products (2768) >
Shipping Guide
Shipping
Delivery Period
For in-stock parts, orders are estimated to ship out in 3 days.
Elecbee ships orders once a day at about 5pm except Sunday.
Once shipped, estimated delivery time depends on the below carriers you chose.
DHL Express: 3-7 business days
DHLeCommerce: 12-22 business days
FedEx International Priority: 3-7 business days
EMS: 10-15 business days
Registered Air Mail: 15-30 business days
Shipping RatesShipping rates for your order can be found in the shopping cart.
Shipping OptionsShipping rates for your order can be found in the shopping cart.
Shipping TrackingWe will notify you by email with tracking number once order is shipped. You can track your order using the “Track My Order” feature.
Returning/WarrantyReturningReturns are normally accepted when completed within 30 days from date of shipment, please contact customer service for a return authorization. Parts should be unused and in original packaging. Customer has to take charge for the shipping
WarrantyAll Elecbee purchases come with a 30-day money-back return policy, plus 1-year Elecbee warranty against any manufacturing defects.
This warranty shall not apply to any item where defects have been caused by improper customer assembly failure by customer to follow instructions, product modification, negligent or improper operation
OrderingHow to BuyElecbee accepts online orders.
Add to cart > Check out > Submit order > Complete payment > Delivery
PaymentPayPal, Credit Card includes Visa, Master, American Express, Bank transfer.
Description

 Feature

  • Female and male, Straight, Waterproof, crimp, 4pin, 4-hole flange;
  • Termination Type:  sloder for plug. crimp for socket
  • Easy quick connect and disconnect coupling;
  • Options: 4/7/40/53/61 pins
  • Hole Diameter: 55mm
  • From the OEM Original Factory, same quality with much better price.

 Main Application of WF55 Connectors:

  • Applications: used in aviation, navigation, computers, communications, navigation, anti-theft devices, transportation, machinery and electronics, etc.

Electrical Characteristics

  • Working Voltage: 500 V rms
  • insulator resistance:2000 ohm
  • test  Voltage:1500 V rms

Mechanical Characteristics

  • Coupling: threaded
  • Mating Durability: ≧500 cycles

Environmental Characteristics

  • Temperature Range: -40°C~85°C
  • IP65

 Materials

  • Part Material Finish
    Body

    •     Zinc alloy chrome plating

    		 silver
    Center Contact Pin gold-plated brass  gold
    Insulator PPS black
