Elecbee 5PCS CD74HC4067 16-Channel Analog Digital Multiplexer Module CMOS 16CH Breakout Board Compatible with Arduino

SKU: EB0049162

Favorites

Key Features

Key Features:

16-Channel Multiplexing for Simplified Wiring: This CD74HC4067 module enables routing 16 analog/digital signals to a single common pin using just 5 control pins (4 address pins + 1 enable pin), ideal for connecting multiple sensors, TTL devices, or communication modules (I2C/SPI) to microcontrollers with limited I/O.
Bidirectional Signal Support: Works seamlessly with both analog and digital signals (voltage ≤ VCC), supporting bidirectional data flow—perfect for two-way communication setups (e.g., routing microcontroller TX to 16 device RX lines with an additional module).
High-Reliability Switching: Features "break-before-make" switching (6ns @4.5V) to prevent crosstalk, low "on" resistance (70Ω @4.5V), and minimal "off" leakage, ensuring stable signal integrity in critical applications.
Wide Operational Range: Operates across 1.2V-6V power supply and -50℃ to 125℃ temperature range, making it suitable for industrial, automotive, and harsh environment projects.
Enable Pin for Flexible Control: The onboard enable pin (active high) allows full disconnection of the common pin (all switches off), adding safety and control flexibility for dynamic system management.
